Pit Covers

The four types are fall elimination, fall prevention (passive barriers such as covers and guardrails), fall arrest (harness-based systems), and administrative controls (warning lines, training, and procedures). A load-rated pit cover is passive prevention: it closes the opening so no one can fall in, with nothing required of the people walking the floor. OSHA’s criteria require covers to support at least twice the maximum intended load (29 CFR 1910.29(e) general industry; 29 CFR 1926.502(i) construction).

In general industry, fall protection is required at 4 feet above a lower level (29 CFR 1910.28(b)(1)); in construction, at 6 feet (29 CFR 1926.501(b)(1)). A pit is a hole in the walking-working surface, so the governing height is the drop to the bottom of the pit. OSHA’s duty to protect holes applies with a cover over the opening, a guardrail around it, or personal fall protection (29 CFR 1910.28(b)(3)).

The 2016 update to OSHA 1910 Subpart D (Walking-Working Surfaces), effective January 2017, is the current general industry standard, and it governs how floor openings such as pits are protected. It aligned general industry with construction and set the 4-foot regime, with covers required to support at least twice the maximum intended load, secured against displacement, and marked (29 CFR 1910.29(e)). Tritech engineers pit covers to the opening and the traffic over it, and documents the load rating for inspection.
